OVERVIEW
Reliable power for very large residential or small business needs. Built to weather the storms, our largest natural gas/liquid propane generators with industrial-grade engines keep your family comfortable and your business running when a utility failure or storm knocks out power.
  • Extreme Durability – Every KOHLER KGR generator undergoes rigorous durability and reliability testing, ensuring longevity. The heavy-duty industrial liquid-cooled engine performs exceptionally well during long runs in extreme heat conditions.
  • Smart – You get steady, high-quality power that protects your electronics from damage.
  • Advanced – The APM402 controller with patented software is compatible with optional accessories that let you monitor your system remotely through your PC
  • Premium Warranty – We’ve got you covered with 5-year, 2,000-hour protection.
THE POWER YOU NEED
  • A popular choice for light commercial applications. System is NFPA 110, level 1 approved when equipped with the necessary accessories and installed per NFPA standards
  • Excellent peak motor-starting capacity: KG100R: 440kVA at 240V
  • Premium power quality Fast-Response™ permeant magnet excitation provides delivers exceptional digital voltage and frequency regulation for smart appliances and electronics
  • Powered by Kohler KG6208THD industrial-grade engine; operation speed 1800 rpm
THE CONVENIENCES YOU EXPECT
  • The APM402 controller provides advanced control, system monitoring and system diagnostics with remote-monitoring capability
  • Quiet, neighborhood-friendly operation with sound similar to a typical central air conditioner
  • Standard steel enclosure with automotive-grade paint
  • Optional corrosion-resistant aluminum enclosure
  • Runs on either natural gas or liquid propane (LPG); simple switching between natural gas and LPG in the field
    SKU: kohler-kg100r Category: Brand:

    Specs

    Model

    KG100R

    Rated kW LP

    100 kW

    Rated kW NG

    100 kW

    Amps LP

    417 amps

    Amps NG

    417 amps

    Peak Motor Starting kVA @240 V

    440 kVa

    Displacement

    6.2 L (378 cu. In.)

    Horsepower

    NG 204 HP, LP 175 HP

    Enclosure Material

    AluminumSteel

    Sound Output During Weekly Exercise

    68 dB(A)

    Sound output During Full-speed Operation

    69 dB(A)

    Response Time

    10 seconds

    Certifications/Listings

    EPACSAcUL Listed

    Automatic Transfer Switch Included

    Sold Separately

    Remote Monitor Available

    Sold Separately

    Off Grid / Utility backup

    Utility Backup

    Weight

    3340 lbs. (3562 kg)

    Alternator Type

    4-Pole, Rotating Field

    Fuel Consumption on NG at 50% Load?

    946 cfh

    Fuel Consumption on LP at 50% Load?

    388 cfh

    Controller

    APM402

    Cylinder Arrangement

    V-8

    Dimensions

    3525 mm x 1154 mm x 1665 mm (138.8 in. x 45.4 in. x 65.5 in.)

    Engine Manufacturer/Description

    KOHLER

    Engine Model

    KG6208THD, 6.2L, Turbocharged

    Engin/Alternator RPM

    1800

    Fuel Type

    Natural Gas | LPG

    Frequency

    60 Hz

    Phase

    Single PhaseThree Phase

    Voltage @60 Hzs

    120/240

    Digital Voltage Regulation

    ±0.5%
