Specs
| Model | Deck Width | Battery | kWh | MSRP |
|---|---|---|---|---|
| SEVZ-52H | 52″ | Vanguard® Commercial Lithium Ion Battery (Fixed to Machine) | 5 | $13,999 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. |
||||
| Product Dimensions | 52″ EVZ |
|---|---|
| Length | 67.5″ |
| Tracking Width | 47″ |
| Width (chute down) | 64.5″ |
| Width (chute in transport position) | 53″ |
| Height | 43″ |
| Weight | 700 lb |
| Battery | |
|---|---|
| Battery | Vanguard® Commercial Lithium Ion (52″) |
| Total Battery Wattage | 5kWh |
| Number of Batteries on Machine | 1 (Fixed to machine) |
| Productivity | Up to 5 acres per charge
*dependent upon actual cutting conditions |
| Charging | |
| Charge Time – Standard Charger | 5.5 Hours (Approximate) |
| Electrical / Instrumentation | |
| Interlock Switches | Seat, Neutral Control, Mower Engagement (PTO) |
| Instrument Panel | Operator Information Display, Key Switch, Light Switch, PTO Switch, E-Stop Switch |
| Mower | |
| Drive System | Hydro-Gear ZT-2800e™ Electric Transaxles (52″) |
| Drive Motor | Brushless DC Motors |
| Parking Brake | Internal / Electrically Activated |
| Drive Tires | 20″ x 10″-8″ (52″) |
| Caster Tires | 11″ x 6″-5″ (52″) |
| Seat | Padded, Thick Cushion with Extra Spring Support and Armrests |
| Forward Ground Speed | 7 mph |
| Reverse Ground Speed | 4 mph |
| Deck | |
| Cutting Widths | 52″ |
| Cutting Height | 1.5″ to 4.5″ in .25″ increments |
| Construction | Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles. |
| Blade Engagement | Electric Brushless DC Motors with Control Panel Engagement (PTO) Switch 1.5 KW Continuous |
| Deck Lift | Foot-operated pedal |
| Type | Heavy-Duty Hero™ Cutter Deck |
| Deck Drive | Smartec® D2e™ motors by Hydro-Gear®; cast aluminum housing |
