Specs
| Model | Tracking Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
| SRC-52D-27CX-EFI | 70″ | Briggs & Stratton® CXi Series™ | 27 | $57,900 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. |
||||
| Product Dimensions* | |
|---|---|
| Length | 75.4″ |
| Width | 70″ |
| Height | 32.5″ |
| Weight (no fuel) |
2400 lbs |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. |
|
| Drive System | |
|---|---|
| Drive System | Electric Drive (No PTO) |
| Type | OMNI |
| Drive Wheel Motors | OMNI |
| Productive Speed Range | Up to 3.0 mph |
| Degree of Slope | Hybrid operation up to 25-degree incline; electric-only operation beyond 25-degrees |
| Steering/Travel Control | Easy-to-use remote control |
| Battery | |
| Battery | ALLIANCE I48-3.0 |
| Number of Batteries on Machine | 3 (fixed to machine) |
| Total Battery Wattage | 9kWh |
| Productivity | Batteries power the machine from 100-20% for approximately 1.5hrs after which the alternator generates power using the 37hp Vanguard engine to charge the batteries and run the machine. |
| Charging | |
| Charge Time – Wall Charger | 100% in about 5hrs |
| Charging Time – Alternator | Charges up to 90% in 5-6hrs via alternator (dependent on cutting conditions) |
| Remote Control | |
| Signal Range | 1000 ft or line of sight (E-Stop on Signal loss) |
| Remote Battery Life | 10 hours |
| Remote Charge Time | 2 hours |
| Deck | |
| Cutting Widths | 52″ |
| Electric Cutting Height Adjustment | 3.5″ to 11.5″ |
| Thickness of brush | Clearing heavy brush up to 1.5” in diameter |
